PD Connex CX100-25 25m DMX Cable for 3-Pin Lighting Control
The PD Connex CX100-25 is a black 25m DMX lighting-control lead with 3-pin XLR male and female ends, made for indoor stage, venue and installation lighting setups.
Technical Specifications
| Cable type | DMX lighting-control cable |
| Characteristic impedance | 120 ohm |
| Cable length | 25m |
| Colour | Black |
| IP Rating | N/A |
| Connector A | 3-pin XLR male |
| Connector B | 3-pin XLR female |
| Conductor size | 28×0.1mm |
| Shielding | 60×0.1mm |
| Outer jacket material | Flexible PVC |
| Cable outer diameter | 6mm |
| Connector material | Metal |
| Cable flexibility | Flexible |
| Suitable for | DMX controllers, lighting fixtures, splitters, interfaces and terminators |
| Use environment | Indoor stage, Venue |
| Warranty | 2 years |
Ideal For
- DMX lighting control in indoor stages and performance venues
- Connecting controllers to moving heads and effects lighting
- Linking LED PAR cans, wash fixtures and compatible splitters
- Permanent lighting installations requiring a 25m cable run
- Technicians and AV teams building tidy, manageable DMX lines
Compatibility and Useful Information
This DMX lighting cable is intended for compatible DMX controllers, lighting fixtures, splitters, interfaces and terminators with 3-pin XLR connections. It is a dedicated 120 ohm DMX wire, so it should be chosen when your lighting equipment calls for DMX XLR cabling rather than a generic audio cable. The 25m length makes it a sensible long DMX cable for larger indoor spaces, while the male-to-female connector format suits standard 3 pin DMX linking between devices.
